Terminal blocks

Order number: No.-poles (Y2500B/V-3P for example)

  • No. Y103 ; 250V 16A
  • Poles: 2P&3P, pitch 5mm
  • Pin dimension:0.8x1.0mm
    Materials:
  • Housing:Polyamide 6.6
  • Solder pin:Brass, 0.8t, Tin plated
  • Wire cage:Steel, 0.7t, Zinc plated
  • Screw:M2.5, steel, Zinc plated
  • No. Y128A/V ; 250V 16A
  • Poles: 2P&3P, pitch 5mm
  • Pin dimension:0.8x0.9mm
    Materials:
  • Housing:Polyamide 6.6
  • Solder pin:Brass, 0.8t, Tin plated
  • Wire cage:Steel, 0.7t, Zinc plated
  • Screw:M2.5, steel, Zinc plated
  • No. Y128A/R ; 250V 16A
  • Poles: 2P&3P, pitch 5mm
  • Pin dimension:0.8x0.9mm
    Materials:
  • Housing:Polyamide 6.6
  • Solder pin:Brass, 0.8t, Tin plated
  • Wire cage:Steel, 0.7t, Zinc plated
  • Screw:M2.5, steel, Zinc plated
  • No. Y2500F-A ; 250V 12A
  • Poles: 2P&3P, pitch 5mm
    Materials:
  • Housing:Polyamide 6.6
  • Clamp:Phos. bronze 0.4t, Tin pl.
  • Wire cage:Steel, 0.7t, Zinc plated
  • Screw:M2.5, steel, Zinc plated
  • No. Y2500A/V ; 250V 12A
  • Poles: 2P&3P, pitch 5mm
  • Pin dimension:1.0x1.0mm
    Materials:
  • Housing:Polyamide 6.6
  • Solder pin:Brass, 1.0t, Tin plated
  • No. Y2500A/R ; 250V 12A
  • Poles: 2P&3P, pitch 5.00mm
  • Pin dimension:1.0x1.0mm
    Materials:
  • Housing:Polyamide 6.6
  • Solder pin:Brass, 1.0t, Tin plated
  • No. Y300/V ; 250V 16A
  • Poles: 2P&3P, pitch 5mm
  • Pin dimension:Ø1.0mm
    Materials:
  • Housing:PBT(30% Glass filled)
  • Solder pin:Brass, Tin plated
  • Wire protector:Steel, 0.2t
  • Screw:M3.0, steel, Zinc plated
  • No. Y300/R ; 250V 16A
  • Poles: 2P&3P, pitch 5mm
  • Pin dimension:Ø1.0mm
    Materials:
  • Housing:PBT(30% Glass filled)
  • Solder pin:Brass, Tin plated
  • Wire protector:Steel, 0.2t
  • Screw:M3.0, steel, Zinc plated
  • No. Y301/V ; 250V 16A
  • Poles: 2P&3P, pitch 5mm
  • Pin dimension:Ø1.0mm
    Materials:
  • Housing:PBT(30% Glass filled)
  • Solder pin:Brass, Tin plated
  • Wire protector:Steel, 0.2t
  • Screw:M2.6, steel, Zinc plated
  • No. Y301/R ; 250V 16A
  • Poles: 2P&3P, pitch 5mm
  • Pin dimension:Ø1.0mm
    Materials:
  • Housing:PBT(30% Glass filled)
  • Solder pin:Brass, Tin plated
  • Wire protector:Steel, 0.2t
  • Screw:M2.6, steel, Zinc plated
  • No. Y332 ; 250V 10A
  • Poles: 2P&3P, pitch 5mm
    Materials:
  • Housing:PBT(30% Glass filled)
  • Wire cage:Brass, Tin plated
  • Clamp:Stainless Steel, 0.2t
  • Screw:M2.6, steel, Zinc plated
Pins for Y332
  • No. Y330/V ; 250V 10A
  • 24P, pitch 5mm
  • Pin dimension:Ø1.3mm
    Materials:
  • Housing:PBT(30% Glass filled)
  • Solder pin:Brass, Tin plated
